C++ Graphics Programming Tutorial: Getting Started with Shapes and Colors

Graphics Programming Using C++ - Lab Handout 1 Computer Graphics (ITEC-613 & SENG-613)

Instructor: Dr. Zeeshan Bhatti

Welcome, future graphics programmers! This tutorial will guide you through the fundamentals of graphics programming using C++ and the Borland Graphics Interface (BGI). By the end of this lab, you'll be creating various shapes and understanding how to work with the graphics coordinate system.

Basics of Computer Graphics | What is Computer Graphics | Computer Graphics full Course Urdu 🎮02

Setting Up Your Environment

Before we begin, ensure you have a Turbo C++ compiler or a modern IDE (like Code::Blocks) with the WinBGIM library installed. You'll need these key files in your project directory:

  • graphics.h (header file)

  • graphics.lib (library file)

  • .BGI files (graphics drivers, particularly EGAVGA.BGI)


1. Your First Graphics Program: Drawing a Circle

Let's start with a simple program that displays a circle on the screen. This will verify that your graphics environment is working correctly.

Example 1: Basic Circle Program

c
/* simple.c - Basic graphics program to draw a circle */
#include<graphics.h>  // Includes graphics functions and constants
#include<conio.h>     // Includes console input/output functions

void main()
{
    int gd = DETECT, gm;  // gd = graphics driver, gm = graphics mode
    clrscr();             // Clear the text mode screen

    // Initialize graphics mode
    initgraph(&gd, &gm, "C:\\TC\\BGI");  // Path to BGI driver files

    // Draw a circle at center (200,100) with radius 150 pixels
    circle(200, 100, 150);

    getch();        // Wait for user input before closing
    closegraph();   // Switch back to text mode and free memory
}

Understanding the Code:

  • graphics.h: The main header file containing all graphics functions

  • conio.h: Provides getch() for pausing the program

  • DETECT: Automatically detects the best graphics driver available

  • initgraph(): Initializes the graphics system (more details below)

  • circle(x, y, radius): Draws a circle with center at (x,y) and given radius

  • getch(): Prevents the window from closing immediately

  • closegraph(): Properly shuts down the graphics system

Expected Output:
A graphics window displaying a white circle centered at position (200, 100) with a radius of 150 pixels.


Understanding Key Graphics Functions

The initgraph() Function

This is the most important function that initializes the graphics system.

Syntax:

c
initgraph(int far *graphdriver, int far *graphmode, char far *pathtodriver);

Parameters:

  • *graphdriver: The graphics driver to use (DETECT for auto-detection)

  • *graphmode: The graphics mode/resolution (set automatically with DETECT)

  • *pathtodriver: Path to the directory containing .BGI files

Common Usage:

c
initgraph(&gd, &gm, "C:\\TC\\BGI");  // Specific path
initgraph(&gd, &gm, "");            // Current directory only

The closegraph() Function

Always call this function at the end of your graphics program to:

  • Switch back to text mode

  • Clear the screen

  • Free allocated memory for graphics system

  • Prevent system crashes or unusual behavior


2. Understanding the Coordinate System

In graphics mode, all coordinates are specified in pixels:

  • Origin (0,0): Top-left corner of the screen

  • X-axis: Increases from left to right

  • Y-axis: Increases from top to bottom

  • Resolution: Typically 640×480 pixels in VGA mode

Visual Representation:

text
(0,0) ────────────────→ X-axis (640)
  │
  │      Your shapes are drawn
  │      within this coordinate
  │      system
  ↓
Y-axis (480)

3. Drawing Basic Shapes

Now let's explore more shape-drawing functions with practical examples.

Example 2: Multiple Shapes Program

c
/* shapes.c - Drawing various basic shapes */
#include<graphics.h>
#include<conio.h>

void main()
{
    int gd = DETECT, gm;
    initgraph(&gd, &gm, "C:\\TC\\BGI");

    // Draw a rectangle: (left, top, right, bottom)
    rectangle(50, 50, 200, 150);

    // Draw a circle: (center_x, center_y, radius)
    circle(320, 120, 80);

    // Draw an ellipse: (center_x, center_y, start_angle, end_angle, x_radius, y_radius)
    ellipse(500, 120, 0, 360, 100, 50);

    // Draw a line: (x1, y1, x2, y2)
    line(50, 200, 600, 200);

    // Draw an arc: (center_x, center_y, start_angle, end_angle, radius)
    arc(320, 300, 45, 270, 60);

    getch();
    closegraph();
}

Shape Functions Summary:

  • rectangle(left, top, right, bottom): Draws a rectangle

  • circle(x, y, radius): Draws a circle

  • ellipse(x, y, st_angle, end_angle, x_radius, y_radius): Draws an ellipse

  • line(x1, y1, x2, y2): Draws a straight line

  • arc(x, y, st_angle, end_angle, radius): Draws an arc


4. Working with Colors

BGI provides 16 colors that you can use to make your graphics more appealing.

Example 3: Colorful Shapes Program

c
/* colors.c - Using colors in graphics */
#include<graphics.h>
#include<conio.h>

void main()
{
    int gd = DETECT, gm;
    initgraph(&gd, &gm, "C:\\TC\\BGI");

    // Set background color to BLUE
    setbkcolor(BLUE);

    // Draw a red rectangle
    setcolor(RED);
    rectangle(100, 100, 200, 150);

    // Draw a green circle
    setcolor(GREEN);
    circle(300, 200, 50);

    // Draw a filled yellow ellipse
    setcolor(YELLOW);
    setfillstyle(SOLID_FILL, YELLOW);
    fillellipse(450, 150, 80, 40);

    // Draw magenta text
    setcolor(MAGENTA);
    outtextxy(200, 300, "Hello Graphics World!");

    getch();
    closegraph();
}

Color Functions:

  • setcolor(color): Sets the current drawing color

  • setbkcolor(color): Sets the background color

  • setfillstyle(pattern, color): Sets fill pattern and color

  • floodfill(x, y, border_color): Fills a bounded area with current fill style

Available Colors:

text
BLACK, BLUE, GREEN, CYAN, RED, MAGENTA, BROWN, LIGHTGRAY,
DARKGRAY, LIGHTBLUE, LIGHTGREEN, LIGHTCYAN, LIGHTRED,
LIGHTMAGENTA, YELLOW, WHITE

5. Creating Patterns and Complex Shapes

Example 4: Pattern Drawing with Loops

c
/* pattern.c - Creating patterns using loops */
#include<graphics.h>
#include<conio.h>

void main()
{
    int gd = DETECT, gm;
    int i, x, y;

    initgraph(&gd, &gm, "C:\\TC\\BGI");
    setbkcolor(BLACK);

    // Draw concentric circles
    for(i = 10; i <= 100; i += 10) {
        setcolor(i/10);  // Change color for each circle
        circle(320, 240, i);
    }

    // Draw a grid of rectangles
    for(x = 50; x <= 550; x += 100) {
        for(y = 50; y <= 400; y += 100) {
            setcolor((x/50 + y/50) % 16);
            rectangle(x, y, x+40, y+40);
        }
    }

    getch();
    closegraph();
}

6. Common Errors and Solutions

Error 1: "BGI Error: Graphics not initialized"

  • Solution: Check the path in initgraph() or ensure BGI files are in your project directory.

Error 2: Program closes immediately

  • Solution: Add getch() before closegraph() to pause execution.

Error 3: Shapes not visible

  • Solution: Check if coordinates are within screen bounds (typically 640×480).

Best Practices:

  1. Always initialize graphics with initgraph()

  2. Always close graphics with closegraph()

  3. Use getch() to pause before closing

  4. Check your coordinate values

  5. Test colors to ensure visibility against background


Practice Exercises

Exercise 1: Create a program that draws the Indian flag using rectangles and a circle.

Exercise 2: Write a program that draws a simple house with a door, windows, and roof.

Exercise 3: Create an animated effect by drawing circles with increasing radii in a loop.

Exercise 4: Draw a bar chart representing monthly sales data.

Exercise 5: Create a colorful geometric pattern using nested loops.


Conclusion

Congratulations! You've taken your first steps into the world of C++ graphics programming. You've learned how to:

  • Set up the graphics environment

  • Draw basic shapes (circles, rectangles, lines, ellipses)

  • Work with colors and fill patterns

  • Understand the graphics coordinate system

  • Create visual patterns using loops

These fundamentals will serve as the building blocks for more advanced graphics programming concepts we'll cover in future labs.

Remember to experiment with different coordinates, colors, and shapes to strengthen your understanding. Happy coding!

Instructor: Prof. Dr. Zeeshan Bhatti
YouTube Channel: Zeeshan Academy
